12L14 Cold Finish Steel Bar
Chemical Composition

Carbon (C)Max  0.15
Manganese (Mn)   0.85-1.15
Lead (Pb)   0.15-0.35
Phosphorus (P)   0.04-0.09
Sulfur (S)   0.26-0.35


Tensile Strength 78 ksi
Yield Strength 60 ksi
Elongation in 2" 10%
Reduction of Area 35%
Brinnell Hardness 163

Typical Uses
12L14 is used extensively in automatic screw machines for manufacturing numerous parts requiring considerable machining and close tolerances, along with a smooth finish. 12L14 can be used to maximum advantage where considerable machining is required, such as bushings, inserts, couplings, and hydraulic hose fittings. With good ductility, 12L14 is suitable for parts involving crimping, bending, or riveting.

12L14 Steel Bar - CF

12L14 Cold Finished Bar is considered to be one of the fastest machining steels currently produced. This has been achieved through the addition and even dispersal of tiny lead particles? throughout the bar. C12L14 gives a smooth, machined surface and because of its low friction component allows increased tool life. This grade is recommended for high-speed automatic screw machine parts.

12L14 bar is a standard resulfurized and rephosphorized grade carbon Steel, and a free machining steel.  The added lead to the chemical composition provides improved machinability. Although the machinability is very good, the added lead content reduces the overall strength of this alloy.
